AutoChimp™ Reverse Camera Kit for Toyota LandCruiser 200 Series GX (2015–2021)

AutoChimp™ Reverse Camera Kit for Toyota LandCruiser 200 Series GX (2015–2021)

Add a reverse camera to a supported LandCruiser 200 Series GX with the matching 6.1-inch factory touchscreen and no existing factory reverse camera. The AC-TOY-24PIN harness fits inline behind the stereo and connects the camera to the factory camera input.

Compatibility

For Toyota LandCruiser 200 Series GX wagons (2015–2021) with the factory touchscreen shown in the fitment images. Match the actual stereo and connector before ordering. Not for VX or Sahara, integrated climate/navigation displays or factory panoramic / 360° camera systems.

Already have a working reverse camera and want additional views? See the Dual Camera Kit for the supported LandCruiser 200 factory screen.

What’s Included

• 1× Pro HD camera with attached 1 m lead, setup loop wires and steel bracket
• 1× Pro mounting bracket with cap
• 1× 7 m camera power/video cable
• 1× AC-TOY-24PIN interface harness
• Installation pack: waterproof sealing tape, split tubing, cable ties, screws, clips and mounting tape

Camera and Display

The Pro HD camera operates on 6–12 V DC and uses the compatible factory stereo’s 6 V camera supply in this installation. CVBS output supports compatible NTSC/PAL screens; it does not convert the factory screen to AHD. Image orientation and parking guidelines are configured using the camera’s setup loop wires.

Operating temperature: −30°C to +70°C. Additional extension cables are sold separately.

Installation Overview

1. Mount the camera and route its 7 m cable to the stereo, protecting and sealing cable entries.
2. Fit AC-TOY-24PIN inline behind the matching factory stereo.
3. Connect the camera cable to the labelled CAM INPUT.
4. Test reverse activation and configure the image before refitting trim.
