The AutoChimp™ Dual Camera Kit (Universal) gives you instant access to multiple camera views using your existing factory or aftermarket screen. This kit combines the powerful AutoChimp™ QuadCam PRO+ Switching Module with the Universal Harness Kit, allowing you to switch between your factory reverse camera and up to three additional cameras — including front, side, or trailer views — at the press of a button.

Designed for any vehicle with an RCA-compatible screen, this system is ideal for custom installs, 4WD builds, or aftermarket setups. It delivers professional-grade performance with clean, reliable installation — no coding, no splicing, and no screen replacement.

🔧 Key Features

• Add Multiple Cameras – Supports up to 4 cameras: reverse + 3 additional (CAM 2, CAM 3, CAM 4)
• Instant Switching – Select views anytime using dash-mounted momentary switches (sold separately)
• Universal Harness Included – Powers up to 3 cameras directly via 12V outputs with ground
• Trigger Inputs – 4x switch inputs and reverse detection to activate display logic
• OEM & Aftermarket Ready – Works with any display that accepts RCA video input
• Built-In Power Outputs – Each camera gets clean 12V from the module, no external wiring needed
• Professional-Grade Install – Ideal for workshops, retrofits, 4WD setups, or trailer systems
• NTSC, PAL, CVBS, AHD Supported – Compatible with AutoChimp™, Safety Dave, and most aftermarket cameras

🎯 Use Cases

• Retrofitting a camera system into older vehicles

• Adding trailer cameras without replacing your stereo

• Expanding visibility with front or side cameras for towing or off-road

• Custom 4x4 builds needing reliable RCA signal switching

📦 What’s Included

• 1x AutoChimp™ QuadCam Switching Module
• 1x AutoChimp™ Universal Harness Kit (AC-QUAD-HRN-UNIV)
  • 12V Power/Ground Harness
  • Reverse Signal Input / Output
  • 4x Switch Trigger Inputs
  • 3x 2-Pin JST Camera Power Leads
  • RCA Video Output Cable
• 1x Mounting Tape
• 1x Digital PDF Installation Guide

 Switch Compatibility (Sold Separately)

• Single Button Switches: CAM 1, CAM 2, CAM 3, CAM 4, TRAILER, FRONT
• Dual Button Switches: CAM 1/2, CAM 3/4, TRAILER/REAR, FRONT/REAR
• Sizes: 22mm, 32mm, 37mm
• LED Colours: Green, Blue, White

⚙️ Any momentary switch that outputs 12V+ is compatible.

⚙️ Technical Specifications

• Video Inputs: 4x (RCA – R-CAM, CAM 2, CAM 3, CAM 4)
• Video Output: 1x RCA (V-OUT to screen)
• Supported Formats: NTSC, PAL, CVBS, AHD
• Power Outputs: 3x JST 2-pin, 12V (2A max per channel)
• Trigger Inputs: 4x switch inputs (12V momentary)
• Reverse Input / Output: Yes
• Voltage: 12V DC
• Operating Temp: -30°C to +70°C
• Mounting: Behind dash or in glovebox
• RCA Output Cable: 300mm
• Power Harness Length: 150mm
• Camera Power Cables: 100mm
• SKU: AC-DUAL-CAM-KIT
• HS Code: 8512.20.00
• Weight: 0.35 kg

📐 Dimensions (for image reference)

• QuadCam Module: 100mm x 80mm x 25mm
• RCA Cable: 300mm
• Camera Power Leads: 100mm
• Main Harness Length: 150–180mm

✅ Why Choose AutoChimp™ Dual Camera Kit

• Keep your factory or aftermarket stereo
• Expand your view and enhance safety with up to 4 camera feeds
• Clean, professional integration for any vehicle
• No coding, no screen replacement, no signal loss
• Trusted by installers and 4x4 owners across Australia
• Built to perform in harsh conditions

SKU: AC-DUAL-CAM-KIT
